To meet the growing demand for 400G-ZR, we have started handling 400G-ZR and 400G-ZR+ High Power.
400G QSFP-DD ZR DCO
PN: OCT-04QD-I1CN101
Description:
OCT-04QD-I1CN101 QSFP-DD transceiver modules are designed for N*400G DWDM transmission system. They are compliant with OpenZR+ standard and QSFP-DD MSA QSFP-DD Hardware Specification.
Key Features
– Hot-pluggable QSFP-DD form factor
– Coherent Optical Technology inside
– Full flexgrid C-band tunable: 191.3~196.1THz
– Modulation: DP-16QAM
– Tx output power: -13dBm ~ -10dBm
– ROSNR: 26dB@400ZR
– Power Consumption: ≤18W
Application:
C-band N*400G DWDM transmission system
Data Rate: 400 Gb/s
Case Temperature: 0~70℃
Transmitter: Nano-ITLA
Wavelength: 1528.77~1567.14nm
Power Consumption (Max): 18W
Please contact us if you need the specification sheet.
0~120km
Voltage Supply
3.3V
Receiver
ICR
Connector
LC
400G QSFP-DD ZR+ DCO
PN: OCT-04QD-I1CN501
OCT-04QD-I1CN501 QSFP-DD transceiver modules are designed for N*400G DWDM transmission system. They are compliant with OpenZR+ standard and QSFP-DD MSA QSFP-DD Hardware Specification.
Key Features
– Hot-pluggable QSFP-DD form factor
– Coherent Optical Technology inside
– Full flexgrid C-band tunable: 191.3~196.1THz
– Modulation: DP-QPSK, DP-8QAM, DP-16QAM
– Tx output power: -13dBm ~ -10dBm
– ROSNR: 24dB@400ZR+
– Power Consumption: ≤21W
Application:
C-band N*400G DWDM transmission system
Data Rate: 400 Gb/s
Case Temperature: 0~70℃
Transmitter: Nano-ITLA
Wavelength: 1528.77~1567.14nm
Power Consumption (Max): 21W
Please contact us if you need the specification sheet.
0~450km
Voltage Supply
3.3V
Receiver
ICR
Connector
LC
